CFV-MZJ70V Veterinary Anesthesia Machine
CFV-MZJ70V Veterinary Anesthesia Machine
CFV-MZJ70V veterinary anesthesia system adheres to the concept of making animal anesthesia safer, simpler, and more reliable, and is committed to leading new experiences in animal anesthesia. Now available as a veterinary anesthesia machine for sale, it is suitable for clinical surgeries in dogs, cats, pigs, monkeys, rodents, reptiles, birds, and more.
CFV-MZJ70V veterinary anesthesia system adheres to the concept of making animal anesthesia safer, simpler, and more reliable, and is committed to leading new experiences in animal anesthesia. Now available as a veterinary anesthesia machine for sale, it is suitable for clinical surgeries in dogs, cats, pigs, monkeys, rodents, reptiles, birds, and more.
Features
Compacted
Space saving, light weight
Ergonomic
Easy to move with mobile handle and silent casters10.2-inch color touch interaction screen with angle adjusted
Integrated
Integrated breathing system and turbine driven. Infusion pump and oxygen generator can be supported
Advanced
Safer treatment with VS and backup mode, minimum tidal volumn 5ml, automatically calculates parameters from weight
Details
Pre-calibrated APL valve to ensure patient safety from high pressure
O2 flush providing high flow oxygen for animal emergency
ACGO reducing the risk of air leakage and breathing system infection
Large capacity sodium lime tank without replacement of sodium lime frequently
Advantages
Efficient
Fast response achieving rapid anesthesia and resuscitation to save time.
Safe
No significant inhibitory effect on respiratory and circulatory function of surgical subjects, no significant by-effects.
Versatile
It can be used in any situation for 0.5-150KG animals surgical anesthesia.
Specification
Physical features
| Machine size | 1534*700*750 mm |
| Machine weight | 55 kg |
| Displays | 10.2 ” TFT- LCD(touch screen) |
| Casters | 4″slient casters with brake |
Pneumatic systems
| Gas source | Types: Oz and Air; or O₂ Connector: DISS or NIST |
| Flowmeter | Oz:0-4 L/min; Air:0-4 L/min |
| ACGO | Yes |
| O₂ flush | 25 -75 L/min |
Electrical
| Input voltage | 100-240V |
| Frequency | 50/60 Hz |
| Input Power | ≤900 VA |
| Power cord | 5m(different standards) |
| Battery | lithium battery*1 |
| Nominal Voltage | 14.4 V |
| Capacity | 6600 mAh, supply <2 hrs |
Anesthetic breathing system
| Bellow | 0~1600 ml or 0~300 ml |
| Absorber canister | 1600 ml or 600 ml |
| Heating function | Yes |
| Bypass function | NO |
Vaporizer
| Type | VP10(Sevoflurane),VP20(lsoflurane),VP40(Halothane) |
| Number | 1 |
| Connector | Selectatec(optional) |
Options
| Optional | ETCO2, O2 sensor, oxygen concentrator |
